The Atosa YCF9409 is a three-door upright freezer with 950 L net capacity and 1390 L gross volume. Its glass doors and interior LED lighting keep frozen products visible, while the 1800 mm width gives buyers a clear footprint for planning display space.
Extra 10% off online
Automatically applied at checkout on $500+ of eligible items (ex GST).
2 years parts and labour, plus 2 years parts-only warranty when registered within 14 days of invoice.
KW Commercial sells Atosa commercial fridges, display showcases and commercial freezers, including bar fridges and cake displays.
View all Atosa products→The YCF9409 provides 950 L of net capacity within a cabinet listed at 1390 L gross volume. Use the net figure when comparing usable storage, and retain the gross figure as a separate supplier measurement. The cabinet is 1800 mm wide, 745 mm deep and 1945 mm high.
Three glass doors and interior LED lighting keep the frozen range visible before a door is opened. The cabinet includes 12 shelves, so check the intended stock layout against the supplied shelf arrangement.
The ventilated refrigeration system is listed with an operating range of -20°C to -17°C. The supplier states operation in an ambient temperature up to 40°C. Ambient conditions describe the room around the cabinet and are separate from the internal operating range.
| Model | YCF9409 |
|---|---|
| Brand | Atosa |
| Dimensions (W × D × H) | 1800 × 745 × 1945 mm |
| Product weight | 240 kg |
| Net capacity | 950 L |
| Gross volume | 1390 L |
| Operating temperature | -20°C to -17°C |
| Shelves | 12; 40 kg supplier-stated load per shelf |
| Construction | stainless steel interior and exterior |
| Refrigerant | R290HC |
| Defrost | Electric |
| Supply | 220 V / 50 Hz / single phase |
| Rated power | 1300 W |
| Mobility | 5 castors, including 3 braked |
| Supplier-stated ambient limit | 40°C |
Check the delivery route, final footprint, door opening space and the refrigeration system’s required ventilation clearance. Confirm the electrical connection and supplied plug or hardwiring arrangement with the supplier; rated power and single-phase supply do not establish the connection fitting.
The supplier states two years of parts and labour cover, with an additional two years of parts-only cover when registered online. Conditions and applicability are governed by the supplier’s current terms.
This model has 950 L net capacity and 1390 L gross volume.
The stated dimensions are appliance dimensions. Confirm required ventilation, service and door clearances separately.
Compare the verified cabinet dimensions, door format, operating temperature, ambient rating and electrical requirements with your site, access path and storage needs.
Check voltage, phase, plug type, and circuit capacity before purchase. Commercial electrical installation must be completed by a licensed electrician.
| SKU | YCF9409 |
| Brand | Atosa |
| Category | Commercial Fridges and Commercial Freezers |
| Weight | 240 kg |
| Dimensions (W×D×H) | 1800 × 745 × 1945 mm |
| Stock Status | In Stock |
| Material | stainless steel interior and exterior |
| Voltage | 220 V |
| Phase | Single Phase |
| Power | 1.3 kW |
| Operating Temperature | −20 °C to −17 °C |
| Packaging Dimensions (W×D×H) | 1855 × 790 × 2050 mm |
