GasMax Superfast Natural Gas Tube - RC300E

• For an LPG supply, choose the RC300ELPG instead of this natural gas model.
• For separate oil tanks, compare the two-tank F-G7215 rather than treating two baskets in the RC300E as separate tanks.

Match the fryer to your gas supply first: this RC300E uses natural gas. This model is also available in LPG — see the RC300ELPG.

Choose a single tank if both baskets will use the same oil. If your workflow needs separate tanks, compare the F-G7215 with two 15 L tanks and two baskets.

Plan the frying station around an 18 L oil fill, a 23 L tank and the 25 kg/h production rating. Check basket loading and the menu's batch sizes before choosing the capacity.

Check the delivery route and final position against the dimensions in Key Specifications above. Allow working access to the drain and front service area, and have the natural gas connection and extraction requirements checked before installation.

• Two baskets and a stainless steel lid are included with the fryer.
• Millivolt mechanical controls provide a 120–200°C temperature range.
• The lift-off basket hanger, oil drain and stainless steel surfaces support clean-down.
• Components can be reached from the front for servicing.

• This version needs a natural gas supply; the LPG version is a separate model.
• The two baskets share one tank, so choose a twin-tank fryer if you need separate oil tanks.
• The working oil capacity is 18 L; compare this with the batch sizes needed during service.

• GasMax Superfast LPG Gas Tube Fryer - RC300ELPG: The RC300ELPG is the LPG counterpart to this natural gas RC300E; choose the model that matches the site's gas supply.
• Fagor F-G7215 Kore 700 Fryer with 2x15L Tank and 2 Baskets: The F-G7215 has two 15 L tanks and two baskets, compared with the RC300E's single 23 L tank and two baskets.

• Gas connection. Have a qualified gas installer check the natural gas supply, 90 MJ/h input, ½-inch inlet connection and extraction arrangements. Select the RC300ELPG if the site uses LPG.
• Position and levelling. Measure the delivery route and working space against the dimensions in Key Specifications above. Use the adjustable legs to level the fryer and leave access to the front, drain and flue area.
• Oil and baskets. Plan operation around the 18 L oil capacity within the 23 L tank. The two supplied baskets share this oil tank.
• Cleaning access. Keep the drain valve accessible and include the lift-off basket hanger and stainless steel surfaces in the cleaning routine. Plan a suitable arrangement for collecting drained oil.
• Service parts. Use the model and serial number when arranging gas-valve or burner servicing. Have a qualified technician match the natural gas parts and serial version before replacing components.

For body dimensions, see Key Specifications above.
