Bonvue HTR160N Chilled Counter-Top Food Display – 146 L / 873 mm
Updated:
At KW Commercial Kitchen, the Bonvue HTR160N is a plug-in chilled counter-top display offering 146 L gross (101 L net) capacity, a 3–8 °C range and fan-forced ventilated cooling in an 873 mm footprint — ideal for cafés, bakeries and butchers showcasing sandwiches, desserts and cold meats in Australia.
Built for Australian front-of-house refrigerated service
The HTR160N combines curved tempered double-glazed front glass, LED illumination and a digital thermostat with auto defrost for stable temperatures and premium product presentation throughout service.
Key features & specifications
- Capacity / Size: Gross 146 L / Net 101 L; Internal 841 × 498 × 384 mm; Shelves 820 × 372 mm + 820 × 408 mm
- Temperature / Power: 3 – 8 °C adjustable range; 160 W fan-forced system; 4.59 kWh / 24 h energy consumption
- Electrical: 240 V / 10 A plug & lead
- Dimensions (W×D×H): 873 × 575 × 676 mm | Weight 71 kg
- Construction: Stainless-steel body; tempered double-glazed curved front glass; sliding rear doors; two adjustable shelves; CFC-free foam; auto defrost; fan-forced ventilated refrigeration; LED lamp illumination
- Controls: Electronic thermostat with digital LED temperature display
- Origin: Bonvue commercial display equipment
- Warranty: 1-year parts & labour
Compliance & safety (AU)
- Electrical: RCM compliant.
- Food safety: Operates within FSANZ 3.2.2A cold-holding guidelines (≤ 5 °C for ready-to-eat foods).
- Gas (if applicable): N/A – electric model.
Convenience & usage advice
- Optimised airflow: Ventilated cooling ensures even temperature throughout the cabinet.
- Low-maintenance design: Auto defrost and CFC-free foam reduce manual servicing and environmental impact.
Ideal applications
- Café cake & dessert display
- Bakery front counter refrigerated unit
- Butcher cold meat and sandwich display
At a glance
- 873 × 575 × 676 mm footprint | 146 L gross / 101 L net capacity
- 160 W fan-forced cooling | 4.59 kWh / 24 h use | 240 V / 10 A
- Stainless steel & tempered double-glazed curved front | LED illumination
- Max ambient 32 °C | Warranty 1 year parts & labour
Frequently Asked Questions
1) How do I clean it daily without harming finishes?
Power off and wipe glass & shelves with a pH-neutral cleaner; avoid abrasives or chlorine; dry thoroughly to prevent streaks or rust.
2) What routine maintenance keeps performance stable?
Clean door seals weekly; vacuum condenser vents monthly; verify LED display accuracy quarterly; keep rear air outlets unblocked.
3) What are the power requirements and typical energy use?
Operates on 240 V / 10 A plug; rated input 160 W (~4.6 kWh / 24 h). See calculator below to estimate daily cost by tariff and hours of use.
4) What about installation and Australian compliance?
Bench-mount with clear ventilation; plug-and-play operation; RCM certified; meets FSANZ food holding standards for cold display.
5) Are spare parts and accessories available?
Replacement LEDs, shelves, glass panels and door gaskets are available — quote model and serial for accurate supply.
Specs source: Bonvue HTR160N datasheet (146 L, 160 W, 3–8 °C, 4.59 kWh/24 h, 873×575×676 mm).
