Bonvue HWB2-102 Backfill Heated Display Cabinet – 953 mm / 1100 W
Updated:
At KW Commercial Kitchen, the Bonvue HWB2-102 is a backfill heated display cabinet with 1.02 m² display area and a 30–90 °C temperature range, designed for commercial hot food service. Its dual-tier stainless-steel shelves, black glass finish, and rear feed design make it a premium solution for cafés, bakeries and hotel passes in Australia.
Built for Australian hot food passes and service counters
The HWB2-102 combines stainless-steel slide guides, mechanical temperature control, and full-glass visibility to create an efficient self-service or staff-served display that keeps food warm, visible, and easily restocked from the back.
Key features & specifications
- Display area: 1.02 m² dual-tier configuration with stainless food slide guide
- Temperature / Power: 30 – 90 °C range; 1100 W rated input; 4.8 A current draw
- Electrical: 220–240 V / 50 Hz / 10 A plug & lead
- Dimensions (W×D×H): 953 × 703 × 704 mm:contentReference[oaicite:0]{index=0}
- Weight: 50 kg (± 5 mm tolerance per drawing):contentReference[oaicite:1]{index=1}
- Construction: Black stainless frame + glass sides; dual-tier stainless shelves; visible temperature display; mechanical controller; rear feed design; robust leg supports; IPX4 splash-proof rating
- Controls: Mechanical dial with analog temperature indicator
- Origin: Bonvue commercial display range
- Warranty: 1-year parts & labour
Compliance & safety (AU)
- Electrical: RCM compliant.
- Food safety: Holds ≥ 60 °C as per FSANZ 3.2.2A for hot-held foods.
- Ingress protection: IPX4 – resists splashing water from all directions.
Convenience & usage advice
- Effortless service: Backfill layout enables smooth food transition from prep area to display front.
- Low maintenance: Mechanical control reduces calibration needs and simplifies cleaning.
Ideal applications
- Café and bakery hot pastry display
- Restaurant or hotel buffet pass
- Convenience store hot snack counter

At a glance
- 953 × 703 × 704 mm | 1.02 m² display area | 50 kg
- 30 – 90 °C adjustable | 1100 W / 4.8 A | 240 V plug-in
- Dual-tier stainless shelves | Mechanical control | IPX4 splashproof
- Warranty 1 year parts & labour | RCM compliant
Frequently Asked Questions
1) How do I clean it daily without harming finishes?
Switch off and cool; wipe glass and shelves with a pH-neutral cleaner; avoid abrasives; dry thoroughly to preserve black finish and seals.
2) What routine maintenance keeps performance stable?
Weekly wipe temperature display and food guide; inspect cable and thermostat quarterly; keep vents clear for even heat distribution.
3) What are the power requirements and typical energy use?
Operates on 240 V / 10 A plug; rated 1.1 kW. See calculator below to estimate daily running cost.
4) What about installation and Australian compliance?
Place on level counter with rear access; ensure 50 mm clearance; RCM electrical compliance; FSANZ food-holding standards (≥ 60 °C).
5) Are spare parts and accessories available?
Replacement glass panels, thermostats and shelf guides are available; quote model and serial for assistance.
Specs source: Bonvue HWB2-102 datasheet & engineering drawing (953 × 703 × 704 mm; 1.02 m² display; IPX4; 240 V / 1100 W).:contentReference[oaicite:2]{index=2}
